Key Features:

• Rugged and Versatile: Designed for harsh industrial environments.
• Dual SIM: Offers connectivity redundancy through failover.
• 4G LTE: Provides high-speed cellular connectivity.
• 4 Ethernet Ports: Enables wired network connections.
• Wi-Fi: Supports wireless connectivity for devices.
• GPS: Provides location tracking and positioning.
• I/O Connector Block: Allows for connection to various external devices and sensors.
• RS232/RS485: Provides serial communication capabilities.
• RutOS Software: Features advanced functionality and extensibility for custom scenarios.
• Remote Management: Supports remote management through the Networks RMS platform.
• Advanced Networking: Supports various protocols like Modbus, SNMP, TR-069, NTRIP, MQTT, and VPN services.

Use Cases:

The industrial router can be used in a variety of applications, including remote camera access, managed print services, construction site Wi-Fi, internet access for RVs and campers, and in various IoT and IIoT deployments. It’s also suitable for applications like vehicle tracking, surveillance systems, and heavy machinery operation.

Specifications:

• 4G LTE: Supports 4G LTE Cat 4, 3G, and 2G connectivity.
• Dual SIM: Features dual SIM failover for continuous connectivity.
• GNSS: Includes GPS, GLONASS, BeiDou, Galileo, and QZSS tracking.

Interfaces:

1. 4x Ethernet ports –

• WiFi (802.11n/g/b).
• RS232/RS485.
• Digital and analog I/O.
• MicroSD card slot.

2. USB interface –

• CPU: Atheros Wasp, MIPS 74Kc, 550 MHz.
• Memory: 128 MB RAM, 16 MB storage.
• Dimensions: 110 x 100 x 50 mm.
• Weight: 287g.

Power:

• Input voltage: 9 – 30 VDC.
• Power consumption: < 7W.
• Operating Temperature: -40° to 75° C.
• Storage Temperature: -45° to 80° C.
• Operating Humidity: 10% to 90% non-condensing.
• Storage Humidity: 5% to 95% non-condensing.
• Mounting: DIN Rail, Tabletop.

Software & Remote Management:

• Software: RutOS with advanced features like Modbus, SNMP, TR-069, NTRIP, MQTT, and multiple VPN services.
• Remote Management:  Networks Remote Management System (RMS) for remote access and management.
