Name: Motion Triggered Switch
SKU: RZ022-5A
Availability: InStock

Motion Triggered Switch

₦30,800.00

In Stock

Key Features:

Occupancy, Vacancy, Manual ON/OFF mode 3 in 1
Exclusive ON/OFF mode allows the sensor switch to work the same as a standard light switch
Time delay options: 15s, 1 min, 3 mins, 5 mins, 15 mins, 30 mins
Enable ambient light sensor to keep lights off when there is ample natural light
Low and high sensitivity adjustable
Adjust settings by tapping buttons without removing the switch plate
Magnetic latching relay provides better performance
Made of fire-resistant materials for your safety
RoHS, CE, FCC certified
Features
Sensor Mode – Vacancy mode, Occupancy mode, Manual ON/OFF mode
Time-Delay -15 s, 1 min(default), 3 mins, 5 mins, 15 mins, 30 mins
Light Sensor – Off, 15 Lux, 25 Lux (default), 35 Lux
Sensor Sensitivity – Low Sensitivity, High Sensitivity
Working Conditions
Power Source – 100 VAC ~ 265 VAC
Power Frequency – 50 / 60Hz
Installation Height – 1.2 m ~ 1.6 m
Working Humidity < 93%RH
Working Temperature – -20 ~ +40℃
Detection Capability
Detection Distance – 7 m ~ 10 m (<27℃)
Detection Range – < 150°
Detection Speed – 0.6 ~ 1.5m/s
Bulb Compatibility
Fluorescent / Ballast / LED – 500 W / 220 VAC
Incandescent / Halogen – 1100 W / 220 VAC

Use Cases:

Smart home
Office

Specifications:

Manual mode allows the switch to work exactly like a light switch
100~265V line voltage, 5A current rating
Neutral Required. European standard.
Occupancy, vacancy, manual override 3-in-1

Description

The motion sensor switch, 100~265V, 5A. Direct replacement for European wall switch. Neutral wire required. Advanced PIR motion sensor for accurate motion detection. Occupancy/Vacancy mode with exclusive manual ON/OFF mode.

The manual ON/OFF mode allows users to keep the load always ON/OFF, just like a regular wall switch. By simply pressing a button on the panel, you can change from Occpuacny/Vacancy mode to manual mode and vice versa without losing any settings. This feature allows users to have permanent manual control of the load and override the motion detecting mode when in need.

This motion sensor light switch also allows users to temporarily turn ON/OFF the light without exiting the current detecting mode and allows 6 levels of time delay adjustment from 15 s to 30 mins and 3 levels of light sensor adjustment from OFF, 15 lux to 35 lux. RZ022-5A provides maximum flexibility and is competent for every home & commercial use case.
